TT ? LAMPS AND JEWEL ASSEMBLIES

230

JACK PANELS

PHONE: 773 792-2700

* Please visit the product pages on our website for the most up-to-date product information

TT ? LAMPS AND JEWEL ASSEMBLIES

Steady “On” Lamp

Series TT450

Blinking/Steady

“On” Lamp

SCHEMATIC

SERIES TT-450 LAMPS

Red LED and series dropping resistor are molded into

compact cartridge with bi-pin terminals for use with TT

Lamp-Jax ? lamp jacks. Colored bezels are molded in for color

coding of functions; colors are black, red, green, white and

yellow. On special order, blue or other colors are available.

Standard voltages are 6, 24 and 48 V (DC only). No tools are

required for lamping/relamping. Simply slip TT-LED into lamp

jack with (+) terminal up. If it doesn’t light, remove it, rotate it

180°, and reinsert it into jack.

SPECIFICATIONS

Housing: Molded black plastic.

Bezel: Molded plastic in colors.

LED: Red illumination.

TT-LED Lamps

Installed

FLASHING/STEADY ON LEDS

Yellow, green and red LEDs are 2-pin cartridge plug-ins which

operate from a 48 VDC supply. When 48 V is applied, LED

flashes for 30 seconds, then changes to steady “On” condition.

SPECIFICATIONS

Body: Thermoplastic, UL 94V-0 rated.

LED Colors: Yellow, green or red.

Pins: T-1 3/4 bi-pin configuration.

Part Number

Description

Part

TT45106

Number

Bezel Part

TT45124 Color TT45224

Voltage TT45148 TT45206 Number Voltage

Bezel

Color

15J9068

15J9076

Red flashing/continuous

Yellow flashing/continuous

TT45248

TT45106

?

TT45306 TT45324 TT45348 TT45406

6

15J9077

Green flashing/continuous

TT45148

? TT45424

48

? TT45448

TT45406

TT45124

TT45548

Red

TT45424 TT45448 TT4506 TT45524

TT45806 TT45824 TT45848

24

48

Blue

15J9078

Amber flashing/continuous

TT45206

TT45224

6

24

Black

TT45506

TT45524

6

24

White

TT-JEWEL ASSEMBLY

TT45248

TT45306

48

6

TT45548

TT45806

48

6

TT45324

TT45348

24

48

Green

TT45824

TT45848

24

48

Yellow

ORDERING

1. Order by part number from table.

2. For special order items, such as other LED colors,

voltages, lamps with 25% reduced power consumption,

etc., contact Switchcraft.

Panel with TT-Jewel Assemblies

and TT-Switches installed

Jewel assemblies use bi-pin lamp and act as lighted jewel and

lamping/relamping tool. Simply slip bi-pin lamp in brass collar

and insert lamp with pins in vertical plane. Lamp automatically

seats properly. Jewel is molded plastic in colors; sleeve is brass.

Part Number

Color

Part Number Color

TT401

TT403

TT404

Red

Green

Blue

TT408

TT413

TT510

Yellow

Amber

Black*

Series TT-450 TT-LED Lamps

TT405

White

*Used as hole plug where

no jack is installed.

LAMPS

Part Number

P2290

P2315

P2316

Description

6.3 V, GE No. 7377.

6.3 V, GE No. 7381. Avg. life: 50K hrs. @ 200 mA.

28 V, GE No. 7387. Avg. life: 25K hrs. @ 40 mA.

Flashing/Steady “On” Lamps

P2456

24 V, GE No. 7001.

DIMENSIONS ARE FOR REFERENCE ONLY

www.switchcraft.com

Inch

(mm)

? Registered trademark of Switchcraft, Inc.

Note: Contact your Switchcraft Representative for price and delivery
